10kΩ Glass Thermistors
Details
- Location: Cabinet-3, Bin 1
- Category: Temperature Sensors
- Type: NTC Thermistor
- Brand: Cantherm
- Part Number: MF58103F3380
- Series: MF58
- Quantity: 50+
- DigiKey Part: 317-1379-ND
- DigiKey URL: https://www.digikey.com/en/products/detail/cantherm/MF58103F3380/1840607
Description
High-quality glass bead NTC (Negative Temperature Coefficient) thermistors with 10kΩ resistance at 25°C. These thermistors are ideal for temperature sensing applications where accuracy and stability are important. The glass bead construction provides excellent long-term stability and resistance to environmental factors.
Specifications
- Resistance @ 25°C: 10kΩ
- Resistance Tolerance: ±1%
- B Value: 3380K (B25/50)
- Operating Temperature: -55°C to 200°C
- Maximum Power: 50mW
- Package: Glass Bead
- Mounting Type: Through Hole
- Lead Wire: Tinned copper leads
Features
- High Accuracy: ±1% resistance tolerance
- Wide Temperature Range: -55°C to 200°C operation
- Glass Construction: Excellent stability and reliability
- Fast Response: Small thermal mass for quick temperature response
- Long-term Stability: Glass bead construction resists aging
- Chemical Resistance: Glass housing protects against environmental factors
Applications
- Temperature Monitoring: HVAC systems, appliances, automotive
- Temperature Compensation: Electronic circuits and sensors
- Overtemperature Protection: Safety circuits and thermal management
- Process Control: Industrial temperature measurement
- Medical Devices: Body temperature monitoring
- Environmental Monitoring: Weather stations, data loggers
Technical Characteristics
Resistance vs Temperature
The resistance follows the standard NTC thermistor equation: R(T) = R₀ × e^(B × (1/T - 1/T₀))
Where:
- R₀ = 10kΩ at T₀ = 25°C (298.15K)
- B = 3380K
- T = Temperature in Kelvin
Typical Resistance Values
| Temperature (°C) | Resistance (Ω) |
|---|---|
| -40°C | ~195kΩ |
| 0°C | ~32.7kΩ |
| 25°C | 10kΩ |
| 50°C | ~3.6kΩ |
| 85°C | ~1.2kΩ |
| 125°C | ~0.5kΩ |
Documentation
- Datasheet: MF58 Series PDF
- Series: MF58
- Manufacturer: Cantherm
Tags
thermistor, ntc, temperature, sensor, glass, bead, cantherm, 10k
Notes
These thermistors are similar to the Cantherm MF58103F3380 and provide excellent temperature sensing capabilities for a wide range of applications. The glass bead construction ensures long-term reliability and stability in demanding environments.
