Yetda Red Alphanumeric Display

Details

• Location: Cabinet-1, Bin 17
• Category: Alphanumeric Displays
• Type: 14-Segment LED Character Display
• Color: Red
• Size: 0.5 inch character height
• Quantity: 8
• Datasheet: https://strawberry-linux.com/pub/yetda%20red%20alphanumeric%20S-10012RSK11.pdf

Description

Yetda S-10012RSK11 red alphanumeric LED display with 14-segment configuration for displaying letters, numbers, and some symbols. Single character display with parallel interface suitable for microcontroller projects.

Specifications

• Part Number: S-10012RSK11
• Character Height: 0.5 inch (12.7mm)
• Segments: 14-segment alphanumeric
• Color: Super Red
• Forward Voltage: ~2.0V per segment
• Forward Current: 20mA per segment (typical)
• Interface: Parallel (direct segment control)
• Package: DIP-style with pins
• Operating Temperature: -40°C to +85°C


Pinout

• Common Anode or Common Cathode: (Check datasheet for specific configuration)
• Segment Pins: Individual pins for each of the 14 segments
• Decimal Point: Separate pin for decimal point control

Applications

• Digital clocks and timers
• Alphanumeric message displays
• Status indicators
• Instrument panels
• Educational electronics projects
• Retro-style displays

Interface Requirements

• Microcontroller: Any MCU with sufficient GPIO pins
• Current Limiting: Resistors required for each segment
• Multiplexing: For multiple displays, consider multiplexing circuit
• Driver ICs: Can use segment driver ICs for easier control

Notes

• Requires current limiting resistors for each segment
• Can display A-Z, 0-9, and some special characters
• Suitable for both static and multiplexed driving
• Classic through-hole mounting style

Tags

led-display, alphanumeric, red, 14-segment, yetda, strawberry-linux
